Completing the Test Point Matrix (TPM) is a necessary step in building a Pogo Pin Cassette. If you would like help drafting the TPM, we can provide this service. The price shown is per test point. The DUT schematic is required for this service.
Integration of TI LAUNCHXL-CC1310 into a Pogo Pin Cassette.
This is used to test Sub-1 GHz RF transmissions used in certain automotive applications. For example, many keyfob entry systems utilize 315MHz or 433MHz transmissions.
High-quality USB-C to USB-C cable with E-marker. This cable is made in-house and each one is individually tested for 100W power delivery. Elastomeric jacket is made of TPE instead of PVC out of concern for the environment. The length is a generous 2 meters. Some folks call this type of cable "EMCA" for electronically marked cable assembly. Includes a cable wrap. Nobody can make a better cable at this price.
Appearance may vary slightly.
Use of Nonstandard Connectors (not including mat'l costs)
Thermal Transfer Printer, which results in a longer-lasting label than a direct thermal printing. This printer supports both methods of printing. High resolution of 300 dpi to support smaller label sizes used in PCB assembly.
